Engine:

130 hp Tier 4 / Cummins diesel

Thrust / Pullback:

27,000 lb (120 kN)

Spindle Torque:

4,000 ft-lb (5,420 Nm)

Spindle Speed:

Up to 220 rpm

Carriage Travel Speeds:

182 ft/min (thrust) / 190 ft/min (pullback)

Ground Travel:

Forward 2.4 mph / Reverse 2.2 mph (varies a little)

Fuel Tank Capacity:

42 gal

Size / Dimensions:

Length 228 in (19 ft), Height 87 in

Drill Pipe / Rod Capacity:

The unit is commonly used with rods that permit installation of utilities up to 4″ diameter (with matching tooling)

Entry / Entry Angle / Stability:

Entry angle range 9°–20°; designed with a low center of gravity, dual stabilizers, etc.
